MicroLux High-Precision Heavy-Duty R8 Miniature Milling Machine

The feature-packed design and robust construction of the MicroLux Milling Machine makes it well-suited for your most demanding model shop projects. Its smooth operation lets you put fine finishes not only on machinable metals, but on non-metals like wood and plastic as well. For operating convenience, we've equipped it with .050 inch-per-turn table feed screws and dials, and the headstock is lever-actuated to make drilling operations a breeze. The column can also be tipped for angled milling and drilling, and easily separates from the base for one-man relocation or storage. The MicroLux Milling Machine is the perfect companion for your MicroLux Lathe . . . it's also backed by Micro-Mark's guarantee of hassle-free product service.

Just Look at These Features

  • Super rigid, heat-treated cast-iron base, column and headstock with precision-ground V-ways

  • Hardened and accurately finished main spindle supported by high precision centripetal roller bearings

  • .050 inch per turn table feed screws with zero-resettable dials

  • Powerful adjustable-speed motor with feedback-sensing power boost circuitry

  • Lever-actuated spring-assisted headstock performs drilling operations with ease

MicroLux R8 Milling Machine Specifications

Table size: 16 inches wide x 3-3/4 inches deep

Table travel (X direction): 8 inches

Cross slide travel (Y direction): 4 inches

Headstock travel (Z direction): 7 inches

Clearance (spindle to table-top): 10 inches

Center of spindle to face of column: 6 inches

Spindle speed: Continuously variable between 0 and 2,500 rpm with belt-driven spindle

Spindle taper: R8

Column angle: tilts from -45 degrees to +45 degrees

Motor: 500 watt (0.67hp) brushless DC, operates from standard 120v AC outlet

Overall size: 30 inches high x 20 inches deep x 20 inches wide

Weight: 110 pounds (basic machine without accessories).

#84630 MicroLux R8 Milling Machine includes variable-speed 500 watt (2/3hp) brushless motor with ultra-quiet belt-driven spindle, 1/2 inch drill chuck and drawbar, table locks, column lock and drill stop, power supply with feedback-sensing power boost circuitry, spring-assisted headstock return, V-way chip guards, chuck/collet chip guard, indicator scales for the X and Z directions, fine-adjust knob for the Z direction, safety cut-off switch, wrench set and instruction manual/parts diagram.

I bought the #84630 Milling Machine...the motor is quiet and hardly makes any noise. Overall, I find this to be a better quality piece of machinery than I had originally expected.
Dan on Yahoo groups

Note: Some assembly required.

Use our web site shopping cart to calculate freight charge for shipments outside 48 contiguous U.S., or call our order line for assistance.

Watch Video



Mill has been equipped with two #84914 twelve-inch capacity digital readout units and one #84911 6-inch capacity DRO unit. Some modifcations are required to mount DRO units to machine as shown. Mounting instructions are not included.

View Instructions

To view instruction manual, click HERE

To view assembly instructions, click HERE
